PRODUCT DESCRIPTION

LOCTITE ABLESTIK 8380 provides the following product

characteristics:

Technology Epoxy

Appearance Silver

Cure Heat cure

pH 4.25

Product Benefits

● Electrically conductive

● Reduced tailing and stringing

Application Die attach

Typical Package

Application

Smart Card

LOCTITE ABLESTIK 8380 electrically conductive adhesive is designed

for advanced, high volume, reel-to-reel smart card applications. This

adhesive is specially formulated to increase assembly productivity and

yield. The rheology of LOCTITE ABLESTIK 8380 adhesive allows

minimum adhesive dispense and die put down dwell times, without

tailing or stringing problems. The rheology of LOCTITE ABLESTIK

8380 adhesive is ideal for high speed automated die bonders. The

adhesive can be dispensed with minimum dwell time, without tailing or

stringing, to maximize die bonder UPH.

TYPICAL PROPERTIES OF UNCURED MATERIAL

Thixotropic Index 4.3

Viscosity @ 25 °C 10,000

Storage Life @ -40°C (from date of manufacture),

 days

365

Flash Point - See SDS

产品描述

乐泰 ABLESTIK 8380 具有以下产品特性：

技术：环氧树脂

外观：银色

固化方式：热固化

pH 值：4.25

产品优势

● 导电

● 减少拖尾和拉丝

应用：芯片贴装

典型封装

应用：智能卡

乐泰 ABLESTIK 8380 导电胶专为先进的、大批量卷对卷智能卡应用而设计。该胶粘剂采用特殊配方，可提高组装效率和

良率。乐泰 ABLESTIK 8380 胶粘剂的流变性能可实现最短的胶粘剂点胶和芯片放置停留时间，且不会出现

拖尾或拉丝问题。乐泰 ABLESTIK 8380 胶粘剂的流变性能非常适合高速自动化芯片贴装机。该

胶粘剂可以以最短的停留时间点胶，且不会出现拖尾或拉丝，从而更大限度地提高芯片贴装机的每小时产量 (UPH)。

未固化材料的典型特性

触变指数 4.3

25°C 时的粘度 10,000

-40°C 下的储存期（自生产日期起）

天

365

闪点 - 参见安全数据表
