Product description

LOCTITE ABLESTIK NCA 01UV provides the following product

characteristics:

Technology UV curable epoxy

Appearance Milky white

Product benefits

Full one step UV cure adhesive

High Tg, low CTE

Low shrinkage

SVHC free and Antimony free

Cure Ultraviolet (UV) light

Application Assembly

Typical assembly

applications ADAS optical modules

LOCTITE ABLESTIK NCA 01UV one step cure adhesive is

specifically designed for automotive Camera Module bonding

applications such as lens barrel-to-housing and lens housing-tocircuit board. The ultimate performance of this material is already

achieved by exposure to UV light of adequate intensity and does not

require a thermal post-cure. This adhesive can be applied by

dispensing.

Typical properties of uncured material

Property Method Typical value

Viscosity@25°C, (mPas.s) @ 15 s-1 27700

Shear thinning index 1.5/15 s-1 5.6

Density, (g/cm³) 25 °C 1.8

Shelf life at -40°C, (mos) 6

产品描述

乐泰 ABLESTIK NCA 01UV 具有以下产品特性：

技术：UV固化环氧树脂

外观：乳白色

产品优势：

一步式UV固化胶粘剂

高玻璃化转变温度 (Tg)，低热膨胀系数 (CTE)

低收缩率

不含高度关注物质 (SVHC) 和锑

固化方式：紫外线 (UV)

应用：组装

典型组装应用：ADAS光学模块

乐泰 ABLESTIK NCA 01UV 一步式固化胶粘剂

专为汽车摄像头模块粘接而设计

例如镜头筒与外壳以及镜头外壳与电路板的粘接。该材料的更佳性能可通过

在足够强度的紫外线照射下实现，无需

热后固化。该胶粘剂可通过

点胶方式涂覆。

未固化材料的典型性能

性能 方法 典型值

25℃粘度 (mPa·s) @ 15 s⁻¹ 27700

剪切稀化指数 (1.5/15 s⁻¹) 5.6

密度 (g/cm³) 25℃ 1.8

-40℃保质期 (月) 6
